The compact public address and voice evacuation control module, certified EN54-16 and EN54-4, features 2 amplification modules of max. 500W distributed to 6 broadcast zones. One-500 is ideal for small to medium-scale installations.
6 output zones, 6x6 matrix, expandable
2 x Class D amplifiers with a maximum power of 500W
2 configurations at 100/70V
included backup amplifier
3 audio inputs (BGM + microphone) + mixed input
contacts for control and noise-gate
input for paging microphone (MPS-8Z) or alarm panel VAP-1
LCD display, access and control
dual player for playback of pre-recorded evacuation and alert messages
phased evacuation
message storage capacity: 10 minutes
rack mountable or surface mount
8+2 GPIO ports
2 x preamplified outputs for external amplifiers
integrated DSP:
3/7 band parametric equalizer on input/output
independent volume control on each input
master volume on outputs
LDA sound enhancer
monitors amplified lines through EOL TFL2S01 units (not included) - does not require return connection to the One-500 unit
