VOID Acoustics Bias Q1+ - A flexible 1200W power amplifier, with 4 channels featuring DSP and AES67. Power output of 4 x 300W at 8Ω. It offers a complete suite of DSP tools through the ArmoníaPlus control software. Delay, E.Q, Input trim, Gain, and Polarity, in addition to our product presets with FIR filters and limiters.
The patented SRM (Smart Rails Management) technology maximises system efficiency and drastically reduces power consumption under any load and usage conditions. The bias amplifiers have extremely low dissipation, reducing the need for external cooling devices.
Bias Q1+ is designed to operate with Lo-Z distributed lines (from 2 Ω) and 70V/100V or any combination of the two.
Applications:
- Small to medium-sized venues
- Bar, club, lounge
- Indoor and outdoor dance events
- Gyms and fitness rooms
- Places of worship
- Live music venues
- Hotels and resorts
- Corporate and AV
- Amusement parks
- Cruise ships
Features:
- Compact size and lightweight, occupying only one rack unit
- Impressive sound quality and reliability
- Extremely efficient power supply, microprocessor-controlled, with built-in PFC (Power Factor Correction) for flawless operation worldwide, with any AC mains voltage in the range of 85-275 VAC, tolerant to peaks of up to 400 V
- Patented SRM (Smart Rails Management) technology
- Responsive under any operating conditions
- Operates with lo-Z (from 2 Ω) and 70V/100V distributed lines, allowing for any mixed load configuration with low and high impedance output
- DSP+ versions extend signal routing capabilities with the integration of AES67 digital audio network architecture
Specifications:
- Number of channels: 4
- Output power: 300 W @ 8 Ω, 300 W @ 4 Ω, 400 W @ 2 Ω
- Bridged output: 800 W @ 4 Ω, 600 W @ 8 Ω
- Height: 44.5 mm
- Width: 483 mm
- Depth: 358 mm
- Weight: 7 kg
- IP rating: IP-20
