Easy-to-use 3-pin XLR adapter (male) with swivel antenna
Wireless DMX eliminates extensive cabling between the DMX controller and DMX-controlled units in lighting installations
Thanks to GFSK modulation with 78 channels, interference-free operation alongside other QuickDMX transceivers and wireless devices in the 2.4 GHz band (e.g., Wi-Fi and Bluetooth)
Simultaneous operation of up to 6 transmitters, allowing control of 3072 DMX channels (6 DMX universes)
From 1 to 512 QuickDMX receivers can be controlled by each transmitter
LED indication for functions
Transceiver, to be used as transmitter or receiver
Can transmit up to 512 DMX channels
Control via QuickDMX; DMX; plug and play
Operating range up to 400 m
Package contents
1 x device, 1 x user manual, 1 x declaration of conformity, 1 x external power adapter, 1 x USB cable
Wireless receiver EUROLITE AKKU QuickDMX
Battery-powered 2.4 GHz wireless DMX receiver
Compact 3-pin XLR adapter (female) with built-in antenna
Wireless DMX eliminates extensive cabling between the DMX controller and DMX-controlled units in lighting installations
32-bit ARM processor for delay-free transmission
Thanks to GFSK modulation with 78 channels, interference-free operation alongside other QuickDMX transceivers and wireless devices in the 2.4 GHz band (e.g., Wi-Fi and Bluetooth)
Group mode
Multicolour LED indicator
Battery operation up to 20 hours
Control via QuickDMX; plug and play
Operating range up to 400 m
Wireless, flexible, and versatile
Package contents
1 x device, 1 x user manual, 1 x declaration of conformity, 1 x external power adapter, 1 x USB cable
Weight:
690 g
Wireless transmitter EUROLITE QuickDMX
Power supply:
100-240 V AC, 50/60 Hz 5 V DC 1 A
IP rating:
IP20
Power connection:
Mains input via coaxial power connector (M) power cable mounting version with AC adapter (supplied)
DMX channels:
Output 512
DMX input:
1 x 3-pin XLR (M)
Control:
QuickDMX; DMX; plug and play
Carrier frequency:
2.4 GHz
Modulation:
GFSK
Parallel mode:
Max. 6 transmitters
Range:
Operating range up to 400 m
Colour:
Silver
Dimensions:
Length: 21.2 cm Diameter: Ø 1.8 cm
Weight:
150 g
Wireless receiver EUROLITE AKKU QuickDMX
Power supply:
5 V DC
Pin configuration:
inside + outside -
IP rating:
IP20
Power connection:
Mains input via coaxial power connector (M) power cable mounting version for USB A mains connection (supplied)
