Monacor ESP-1000AB

Monacor ESP-1000AB, wall PA speaker A/B, certified EN 54-24 for voice alarm systems with A/B distribution of speakers, according to EN 60849.

• 100 V transmission technology
• 2 x 4" (10 cm) wideband speakers
• 2 separate transformers, with power taps of 6/3/1.5 W each
• power: 2 x 6/3/1.5 W
• frequency range 80-20,000 Hz
• SPL 2 x 92 dB (1 W/1 m) 76 dB (EN, 1 W/4 m)
• max. nominal SPL 2 x 100 dB (1 m) 85 dB (EN, 4 m)
• dispersion angle/radiation 180° (500 Hz) 180° (1 kHz) 130° (2 kHz) 95° (4 kHz)
• connection via 2 ceramic terminals with screws, inside the housing
• metal housing with a metal front grille for protection
• delivered with aluminum mounting bracket, screws and plugs
• dimensions: Ø 220 mm x 100 mm
• weight: 1.98 kg
