LD Systems MAUI 11 G3 SUB - Simply position the SUB next to the MAUI® 11 G3 with the rear facing, activate the Cardioid preset, and you will have a quieter and more controlled low-end at the back, while still maintaining the punch at the front. The low-end frequencies from the back of the system will be attenuated by -15 dB. For additional bass, keep the SUB in the same direction as the MAUI® 11 G3 and deactivate the Cardioid preset.
Setting up the SUB with the MAUI® 11 G3 is simple and quick. Thanks to its automatic detection system, the SUB immediately switches to FOLLOWER mode as long as no column is connected.
A protective cover and a wheel plate are also recommended to make transport easy and to keep the SUB in good condition for as long as possible without any tour damage.
The MAUI® 11 G3 SUB has the same design construction as the MAUI® 11 G3 subwoofer and will be the perfect complement to gain control over the low-end.
Features:
- Bluetooth audio streaming
- Cardioid column
- DSP-based signal processing
- Excellent sound dispersion
- Mono/stereo application
Technical Specifications:
- General:
- Colour: Black
- Max. SPL (peak): 125 dB
- Frequency response (-10dB): 39 - 20,000 Hz
- Weight: 20.5 kg
- Subwoofer:
- Woofer: 2 x 8"
- Magnet: Ferrite
- Voice coil: 2"
- Cabinet construction: Bass Reflex
- Cabinet material: 15 mm birch plywood
- Cabinet surface: Polyurethane
- Dimensions: 305 x 607 x 403 mm
- Weight: 20.5 kg
- Amplifier module (integrated in subwoofer):
- Amplifier: Class D
- Power (RMS): 730 W
- Power (peak): 1460 W
- Protection circuits: DC protection, multiband limiter, short circuit, thermal protection
- Cooling: Convection
- Controls: Bluetooth HOLD TO LINK button, Cardioid On/Off, Master level, Power On/Off, Secondary level
- Indicators: Bluetooth, Cardioid On/Off, Follower mode, Limiting, Power, Protection (protection circuit activated), Signal, Subwoofer mode
- Network connector: IEC power cable (included)
- Voltage: 100 V AC - 120 V AC, 50 - 60 Hz, 220 V AC - 240 V AC, 50-60 Hz
- Fuse: T 3.15AL / 250 V
- Power consumption: 300 W
- Operating ambient temperature: 0 - 40 °C
- Relative humidity: < 80% (without condensation)
- Line inputs: 2
- Line input connectors: Combo XLR / TRS
- Line outputs: 1 x Sub OUT, 2 x THRU
- Line output connectors: XLR female
- Number of speaker outputs: 1
- Speaker output connectors: Custom multi-pin
- Bluetooth standard: A2DP
- Bluetooth audio decoder: AAC, SBC
- DSP Features:
- AD/DA converter: 24 bits
- Sampling frequency: 48 kHz
