Fonestar SONORA-8TB

Fonestar SONORA-8TB - Professional installation speaker with 100 V line transformer and low impedance option, designed for public address applications, ambient music, and background sound. Part of the SONORA series developed by FONESTAR, this model combines high-level acoustic performance with a durable construction, ready for outdoor use, including in marine environments, thanks to the powder-coated aluminium grille and IP-66 protection.

With an extended frequency response and clear sound, free from distortion, the SONORA-8TB ensures effective coverage in commercial and institutional spaces. Installation is quick and secure, supplied with adjustable mounting bracket, stainless steel screws, and safety cable. It is the ideal solution for restaurants, cafes, shops, shopping centres, or any other space that requires reliable, discreet, and high-quality sound.

FEATURES:

• Speaker with low impedance and 100 V line transformer
• Suitable for outdoor use, with waterproof and corrosion-resistant materials

POWER:

• 150 W maximum power
• 100 W RMS

DRIVERS:

• 1 x 8" polypropylene woofer
• 1 x 1" tweeter

FREQUENCY RESPONSE:

• 60 – 20,000 Hz

IMPEDANCE AND POWER LEVELS:

• 80 W RMS @ 100 V – 125 Ω
• 40 W RMS @ 100 V / 70 V
  • 250 Ω / 122 Ω
• 20 W RMS @ 100 V / 70 V
  • 500 Ω / 245 Ω
• 10 W RMS @ 100 V / 70 V
  • 1000 Ω / 490 Ω
• 5 W RMS @ 70 V
  • 980 Ω
• Low impedance: 8 Ω

SENSITIVITY:

• 89 dB @ 1 W / 1 m

MAXIMUM SOUND PRESSURE:

• 108 dB @ maximum power / 1 m

COVERAGE ANGLE:

• 120° horizontal x 120° vertical @ 1 kHz (-6 dB)

PROTECTION:

• IP-66 protection rating according to EN 60529
• Environmental test IEC 60068-2-11 (salt mist)

MATERIAL:

• ABS housing with UV resistance
• Front grille made of aluminium, powder-coated in electrostatic field
• Weather-resistant mounting bracket
• Stainless steel screws

SELECTOR:

• Switch for selecting operating mode (100 V / 70 V / 8 Ω)

CONNECTORS:

• Euroblock IN and OUT for cables with cross-section between 0.25 – 2.5 mm²

OPERATING TEMPERATURE:

• From -10°C to +60°C

COLOUR:

• White (RAL 9003)

DIMENSIONS:

• Speaker: 235 x 380 x 205 mm (depth)
• Wall mounting plate: 102 x 165 mm
• Speaker with mounted bracket: 305 mm depth

WEIGHT:

• 3 kg

INCLUDED ACCESSORIES:

• Adjustable mounting bracket ± 60° in all directions
• Safety cable made of steel
