Fonestar SONORA-3TN

Fonestar SONORA-3TN -  Passive installation speaker, equipped with a transformer for 100 V lines and an option for low impedance operation, specially designed for ambient sound reinforcement and public address applications. It is part of the SONORA series, created by Fonestar based on solid experience in the professional audio field, and offers an excellent balance between aesthetics, performance, and functionality.

The elegant design and premium finish allow for discreet integration of the speaker into any type of decor, whether in restaurants, cafes, shops, offices, or other commercial spaces. The sound quality is clear and free of distortions, ideal for playing background music or transmitting vocal messages. Installation is simple and quick, thanks to the included accessories, such as the adjustable bracket and mounting system.

FEATURES:
• Speaker for professional sound reinforcement, with a transformer for 100 V lines and an option for low impedance operation

POWER:
• 20 W maximum
• 12 W RMS

BUILT-IN SPEAKERS:
• 1 x 3” woofer

FREQUENCY RESPONSE:
• 130 – 20,000 Hz

IMPEDANCE:
• 12 W RMS @ 100 V (833 Ω)
• Low impedance: 8 Ω

SENSITIVITY:
• 84 dB @ 1 W / 1 m

MAXIMUM ACOUSTIC PRESSURE:
• 94 dB @ maximum power / 1 m

COVERAGE ANGLE:
• Horizontal / Vertical:
 – 270° / 270° @ 500 Hz
 – 180° / 180° @ 1 kHz
 – 120° / 120° @ 2 kHz
 – 100° / 100° @ 4 kHz (–6 dB)

MATERIAL:
• ABS housing with UV protection
• Front grille made of aluminium, painted in electrostatic field
• Weather-resistant bracket
• Stainless steel screws

SELECTOR:
• Switch for selecting between high impedance (High Z) and low impedance (Low Z)

CONNECTORS:
• Euroblock terminal (input and output) for cable with a cross-section of 0.25 – 2.5 mm²

TEMPERATURE RANGE:
• –10°C to +60°C

COLOUR:
• Black (RAL 9005)

DIMENSIONS:
• Speaker: 97 x 110 x 107 mm (depth)
• Wall mounting plate: 67 x 71 mm
• Speaker with bracket: 150 mm (depth)

WEIGHT:
• 0.7 kg

ACCESSORIES:
• Adjustable mounting bracket
 – Horizontal adjustment: ±30°
 – Vertical adjustment: +15° / –45°
