1 feed-through output (optionally XLR or 6.3 mm jack)
Master control
LED indicators for power, level, clip and fault
(19") 48.3 cm rack installation 2 U
Package contents
1 x user manual, 1 x amplifier, 2 x holder, 4 x screw
Power supply:
230 V AC, 50 Hz
Power consumption:
720 W
Output power:
360 W RMS
Power connection:
Fixed power supply cord with safety plug
Frequency range:
80 - 16000 Hz
S/N ratio:
>90 dB
THD:
<0,5 % at 1 kHz
Impedance:
4-16 ohms; Public address systems 100V; Public address systems 70V
Circuitry:
Class AB
Controls:
Softstart; overheat; overload; short-circuit; DC voltage
Status LED:
Level meter, power, fault, clip
Connections:
Input: line via 1 x 6.3 mm jack socket (mono) mounting version Input: line via 1 x 3-pin XLR 0,8 V Output: line via 1 x 6.3 mm jack socket (mono) mounting version Output: line via 1 x 3-pin XLR
