Sennheiser Spectera Base Station


Bidirectional wireless system

  • sistem wireless bidirecțional cu până la 64 canale.
  • interfață audio Dante redundantă, cu opțiune MADI.
  • transmisie audio AES 256; până la 64 canale.
  • control de la distanță prin interfață de rețea RJ45.
Sennheiser
9 54835
Currently unavailable. Request details
Central warehouse: 0 In stores: 0
Add to cart
also deliverable via  Deliverable via parcel locker
48681 points of loyalty
Shipping free
Warranty 24 months
Returns 14 days

Sennheiser Spectera Base Station - Bidirectional wireless base station, receiver and transmitter, designed for complex professional audio applications.

Offers up to 64 audio channels with low latency and native integration into IP audio networks, making it ideal for live productions, broadcasting, and large-scale installations. The system ensures maximum reliability through extended redundancy, advanced security, and flexibility in RF spectrum configuration.

Features:

  • Bidirectional wireless system with up to 64 channels (32 inputs / 32 outputs)
  • Support for up to two independent wideband RF carriers
  • Redundant Dante audio interface, with optional redundant MADI
  • Extended redundancy: power, audio network, and antennas
  • Secure audio transmission via AES 256 encryption
  • 11 Audio Link modes with OPUS, SeDAC, or PCM codecs
  • Adjustable RF power between 10 and 100 mW
  • Full remote control via RJ45 network interface
  • Future expansion capability via Cascade port
  • Robust 19” / 1RU metal housing, with OLED display and front control

Technical specifications:

  • Rack format: 19” / 1 RU
  • Audio channels: up to 64 (32 In / 32 Out)
  • RF carriers: up to 2, UHF or 1G4 (6 or 8 MHz, depending on region)
  • Sampling rates: 48 kHz and 96 kHz
  • Sampling rate converters: individual for all audio interfaces
  • Audio interfaces:
    • Redundant Dante® (2 × RJ45, 1 Gbps)
    • Optional redundant MADI (OM or BNC)
  • Wordclock: I/O BNC
  • RF power: 10 – 100 mW (depending on local regulations)
  • Power consumption: 70 W × 2 (redundant power supplies)
  • Antenna ports: 4 × Ethernet for redundancy and extended coverage
  • Connectors: 6.3 mm TRS, BNC 75 Ohm, RJ45 (Ethernet/Dante), SFP
  • Colour: Black
  • Dimensions: 175 x 550 x 435 mm
  • Weight: 8.2 kg

Product code: 509162

Unit of sale: piece

Documentation, manuals:
