Studiomaster Vortex 10A - 2.1 Power Set 2

Studiomaster VORTEX 10A - Active speaker with high-performance amplifiers and a peak of 1400 W and coaxial speaker, Bluetooth connectivity with TWS (True Wireless Stereo) and integrated DSP.

• Type: 10" 2-way coaxial active
• Max SPL: 124 dB
• Peak: 1400 W
• Max PGM: 700 W
• RMS: 350 W (300+50)
• Weight: 12.5 kg
• Frequency response: 55Hz-20kHz
• Coverage: 80 x 80 degrees
• LF Driver: 10″ / 50mm VC
• HF Driver: 1" / 34 mm VC
• Crossover frequency: 2.2 kHz
• 24-bit DSP: Mode selection, 3-band EQ, delay, volume
• DSP Modes: Music, live, dj, speech, monitor
• Connection: 2x XLR/JACK inputs, 1x 3.5 mm, XLR output
• Connectivity: BLUETOOTH playback
• Mounting: Dual top-hat, 5x M10 points
• Dimensions: 310 x 515 x 280 mm

Studiomaster VORTEX 15SA - Active subwoofer that offers a maximum power of 2400 W, low frequencies between 43 and 150 Hz. It is made of 15 mm plywood with a durable finish and features large transport handles. The 35 mm top-hat makes moving and installing this system very simple, and the dual inputs and user-friendly DSP allow the VORTEX 15SA to be set up in seconds.

• 15" active subwoofer
• Max SPL of 132dB
• Amplification/Power:
  • PEAK: 2400W
  • PGM (Program): 1200W
  • RMS: 600W
• Frequency response 43Hz-150Hz
• Input sensitivity 0dBu
• Low driver 15" / 75mm coil
• Crossover frequency 120Hz
• DSP-24bit: Low cut / delay / volume
• Connection
  • 2 x balanced XLR inputs
  • 2 x balanced XLR outputs
• 15 mm plywood cabinet
• Dimensions (width x height x depth) 460 x 580 x 580mm
• Weight: 31kg
