Studiomaster HX2-700

Digital Power Amplifier

ultra-lightweight and compact design with high efficiency.
universal power supply from 90-250V for versatile use.
multiple output power options, including 2 x 595 W at 4 ohms.
advanced thermal and overload protection for reliability.
various modes including stereo, parallel, and bridge.

387⁰⁶ €

In stock and deliverable.

Central warehouse: 1

Add to cart

1927 points of loyalty

Shipping free

Warranty 36 months

Returns 14 days

request details better price?

Studiomaster HX2-700 Add to cart: 387⁰⁶ €

Studiomaster HX2-700 - The HX series includes ultra-lightweight, compact digital amplifiers with astonishing performance.

All models feature advanced protections and status indicators and are available in 2 and 4 channel variants, offering from 2 x 225 watts at 4 ohms up to 4 x 765 watts.

For demanding installations, conferences, entertainment, and smaller touring and rental applications, the new HX series will provide the performance, power, and reliability you need in a compact and affordable package.

Energy-saving design with high efficiency
Power Factor Correction (PFC)
Universal power supply 90-250V
Reliable and efficient operation up to 2 ohm loads
Variable speed fan cooling
Status indicators and protection
Stereo/parallel/bridge modes
Multiple Gain modes
Output limiter
Balanced XLR inputs
Professional speaker connectors
Thermal, overload, DC protection
Thermal, fault, and limiter indicators
Slope (1kHz, Bypass LPF): 50V/us
Input sensitivity: 1Vrms
Frequency response (rated output power 10%, 8 ohms, 20 Hz – 20 kHz): 0.2 dB
Input impedance: 20k ohms (balanced), 10k ohms (unbalanced)
Power supply: 90-260VAC, 50/60Hz
Protections: Overload/thermal/output
Dimensions: 483 mm x 44 mm x 323 mm
Weight: 5 kg
Power:
- 8 ohms stereo: 2x 350 W
- 4 ohms stereo: 2 x 595 W
- 2 ohms stereo: 2 x 1015 W
- 16 ohms bridged: 700 W
- 8 ohms bridged: 1190 W
- 4 ohms bridged: 2030 W
