The XKB series speaker systems are high-performance active speaker systems housed in lightweight and robust plastic enclosures. They can be flexibly used for permanent installations and professional live applications. The 2-way speaker systems are designed as bass-reflex systems with full range, featuring separate power amplifiers for high and low frequency ranges, with inputs for microphones and line sources and parallel outputs for coupling with other active speakers. The DSP (digital signal processor) offers convenient presets for quick sound contouring (models XKB-212A and XKB-215). The built-in Bluetooth player allows wireless music streaming from smartphones or tablets via Bluetooth. The speaker systems are protected by limiters and extensive protection circuits. The enclosure provides multiple configuration options (use as a floor monitor, wall mounting, or on a stand).
Active speaker with 8" woofer, 1" driver, LF: 70 W RMS, HF: 35 W RMS
- Class D bi-amplifier (LF 70 W, HF 35 W)
- Integrated Bluetooth audio streaming
- Bass-reflex enclosure with 2-way configuration featuring a 20 cm woofer and 2.5 cm driver
- 1 microphone/line input (XLR/jack) with level control
- 1 line input (RCA) with level control
- Main control with 2-band EQ, limiter LED, and power
- Bluetooth control
- Black metal grille with acoustic foam
- 3 robust carrying handles
- Application possibilities: on feet; monitoring; on tripod
Package contents
- 1 x compact speaker, 1 x user manual, 1 x power cable, 1 x declaration of conformity
| Power: | Program: 140W
Rated: 35 W RMS HF
Nominal power: 70 W RMS LF |
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power connection: | Network input via IEC (M) connector with power cable mounting version with safety plug (provided) |
| Frequency range: | 65 - 20000 Hz |
| Sensitivity: | 94 dB |
| Control: | Bluetooth |
| Mounting system: | Thread: Ø 36 mm |
| Circuits: | Biamp class D |
| Controls: | Limiter |
| Connections: | Input: microphone via 1 x combined XLR/6.35 mm (F) with 3 pins (mounting version)
Input: line via 1 x RCA stereo
Output: line via 1 x XLR with 3 pins |
| Input channels: | 1 x mono with Mic-line switch via combined socket (XLR/jack), channel control via rotary selector
1 x stereo via RCA or Bluetooth, channel control via rotary selector |
| Equalizer: | Master: 1 tone control with 2 bands |
| Speaker: | 1 x woofer (8") approximately 20 cm
Voice coil drop (1.35") approximately 3.5 cm with ferrite magnet
High compression tweeter (1") approximately 2.5 cm |
| Speaker type: | Compact cabinet speaker |
| Construction type: | Ventilated |
| Carrying handle: | 3 pcs/piece |
| Material: | Plastic |
| Dimensions: | Width: 26 cm
Depth: 27 cm
Height: 43 cm |
| Weight: | 6.90 kg |
