Studiomaster AX225

Power Amplifier

professional quality power amplifier with high output in a compact design.
ideal for stereo or mono bridged applications with built-in bi-directional crossover.
rMS power output of 750 W at 4 ohms, with various protection features.
frequency response from 20Hz to 20kHz and THD distortion of 0.01-0.02%.
dual variable cooling fans and selectable crossover at 100/150Hz.

542³⁹ €

In stock and deliverable.

Central warehouse: 7 In stores: 1

Add to cart

2674 points of loyalty

Shipping free

Warranty 36 months

Returns 14 days

request details better price?

Studiomaster AX225 Add to cart: 542³⁹ €

Studiomaster AX225 - A power amplifier that offers professional quality and high power in a compact package. Alongside the Hi-Pass filters, stereo crossovers, and the two cooling fans, the greatest asset of the series is the impeccable sound.

The AX amplifiers are perfect for stereo or mono bridged applications and with the help of the built-in bi-directional crossover, they fit practically any application.

Input sensitivity: 4 ohms 0 dBu 0.775V
THD distortion: 1kHz @ 0.01-0.02%
Frequency response: 20Hz – 20kHz (+0/-0.5dB)
S/N ratio: 4 ohms 100dB
Input filter: 18dB/oct 35Hz
Crossover: 100/150Hz selectable
Cooling: Dual variable fans
Protections: short circuit, open circuit, thermal, ultrasonic and RF protections
Power requirements: 230V +/-10% 50/60Hz
Input connectors: Combo XLR and Jack, XLR female link socket
Output connectors: 4-pole socket
Both channels @ 8ohms RMS: 450 W
Both channels @ 4ohms RMS: 750 W
Both channels @ 2ohms RMS: 990 W
Bridged @ 8 ohms RMS: 1500 W
Bridged @ 4 ohms RMS: 1950 W
Output circuit: AB+H(2)
Dimensions: 482 x 89 x 394 mm
Weight: 19 kg
