Adam Hall 4 STAR DGH 2000 IP65
3803 €
Currently unavailable.
Request details
Central warehouse: 0
Specifications:
Cable length: 20 m
Cable jacket: PVC (Polyvinyl chloride)
Cable diameter: 6.5 mm
Cable colour: Black
Connector type plug 1: XLR 5-pole female
Model name plug 1: Adam Hall K4CXF5IP65
Connector type plug 2: XLR 5-pole male
Model name plug 2: Adam Hall K4CXM5IP65
Conductor material: OFC (Oxygen-free copper)
Conductor diameter: 2 x 0,34 mm²
Capacity/m: 65 pF
Conductor impedance/km: 53 Ohm
Shield: Braided copper shielding
Protection class: IP65
Ambient temperature: -20 - 70 °C
Weight: 580 g
Product type: Bulk Cable
Type: DMX & AES/EBU Cable
Color: Black
Overall diameter: 6.5 (+/- 0.2 ) mm
Center conductor cross section: 0.34 mm²
Center conductor material: Copper, OFC
Center conductor construction: 7 x 0.25 mm
Number of internal conductors: 2
Shield material: copper
Shield: Braided shielding
Line resistance: 53 Ohm(s)
Capacitance: 65 pF/m
Jacket material: PVC
Weight: 0,05 kg
Product type: Plugs and Connectors
Type: XLR Connectors
Poles: 5
Gender: female
Cable diameter: 3.5 - 8 mm
Contacts: gold plated
Connection type: solder contacts
Color: silver, black + orange
Housing: die-cast zinc
Length: 73.6 mm
Diameter: 16,8 mm
Weight: 0,02 kg
Product type: Plugs and Connectors
Type: XLR Connectors
Poles: 5
Gender: male
Cable diameter: 3.5 - 8 mm
Contacts: gold plated
Connection type: solder contacts
Color: silver, black + orange
Housing: die-cast zinc
Length: 70.8 mm
Diameter: 18.9 mm
Weight: 0,02 kg
Product code: K4DGH2000IP65
Unit of sale: piece
Specifications:
| Connector type: | XLR 5 |
| IP protection grade: | IP65 |
| Length (meters): | 20 m |
