Tascam VS-R264

Tascam VS-R264 is an AV-over-IP video streamer/recorder that offers encoding, streaming, recording, and decoding of audio/video materials simultaneously in Full HD resolution using H.265/HEVC or H.264 video codecs.

It can be used for broadcasts over corporate networks and WANs or for live streaming on the internet; automatic FTP upload of recorded files is also possible. It uses open streaming formats and protocols and is compatible with platforms such as YouTube, Wowza, Ustream, AWS Elemental MediaLive, CloudFront, and others.

Technical specifications:

• HDMI Input: HDMI v1.4a (Type A)
• HDMI Output: HDMI v2.0 (Type A)
• Input Resolutions: 1080p, 720p, 576p, 480p
• Encoding Resolutions: 1920x1080p, 1280x720p, 950x540p, 720x576p, 720x480p, 640x360p, 480x270p, 320x180p
• Encoding Format: H.264 (baseline, main, high)
• Bit Rate Encoding: 500 kbit/s up to 30 Mbit/s
• Bit Rate Control: Variable, Constant
• Analog Audio Inputs: 3.5 mm Jack and Euroblock
• Analog Audio Outputs: Euroblock and 3.5 mm Jack
• Audio Codec: AAC, 64–512 kbit/s, 32/44.1/48 kHz
• Video Transport Protocols: RTMP/RTMPS, RTSP, HLS, RTP/UDP
• Network Connectivity: Gigabit Ethernet
• Power Supply: PoE+ AC Adapter or Tascam PS-P1220E
• Dimensions: 214 x 45 x 136 mm
• Weight: 0.85 kg
• Operating Temperature Range: 0–40 °C
