Audac SMA 350 - WaveDynamics™ power amplifier with two channels, featuring an RMS power of 350 W, Class D technology, and SpeakOn / Dante / EURO-BLOCK-TERMINAL / XLR connections.
RMS/AES Power
At 4 Ω Stereo 2 x 350 W
At 8 Ω Stereo 2 x 220 W
At 8 Ω Bridge 700 W
Frequency Response (± 3 dB) 20 Hz - 20 kHz
Signal / Noise > 95 dB
THD+N (@ 1 kHz) < 0.05% (1/2 nominal power)
Crosstalk (@ 1 kHz) > 70 dB
Class D Technology
Inputs:
Input sensitivity -19.5 dB ~ 27 dB
Impedance 10 kΩ balanced
XLR and EURO BLOCK TERMINAL connector with 3 pins (3.81 mm)
Outputs
compatible with Speakon and Euro terminal block with 2 pins (5.08 mm)
Common Mode Rejection Ratio 70 dB
Damping Factor > 200
Amplifier Protection
DC short circuit
Overheating
Overload
Signal limiting
Speaker Power Limiter
User and administrator access (via password protection and USB key)
