Palmer PAN-16, passive DI unit with 8 channels. Through the special MERGE LINK/IN functionality on each input channel, the LINK output on the front panel can be used as an additional input. The signal is combined with the signal from the standard input. 2 PAD buttons provide attenuation of 10, 20, or 30 dB. The outputs are electrically isolated and transformer balanced.
Passive DI with 8 channels
Inputs: 8 / 16, 6.3 mm jack
Maximum input level: + 54 dBu
Attenuation pad 0 / -30 dB
Outputs: 8 + 8 + Parallel Thru, XLR and 6.3 mm jack
Maximum output level: +4 dBu
Output impedance: 600 Ohms
Frequency range: 10 Hz - 40 kHz
Balancing transformer
Ratio: 10:1
Controls: ground-lift, merge, PAD -10dB, PAD -20dB
