Klotz installation speaker cable - LHC2x 4.0 mm² - PVC - bk - 300 m

Speaker cable

potrivit pentru instalații în clădiri
manta tubulară, Rezistență la flacără
lungime cablu: 300 m, secțiune: 2 x 4.0 mm²

Variants:

1 461²⁹ €

Currently unavailable. Request details

Central warehouse: 0

Add to cart

also deliverable via

7393 points of loyalty

Shipping free

Warranty 12 months

Returns 14 days

request details

Klotz installation speaker cable - LHC2x 4.0 mm² - PVC - bk - 300 m Add to cart: 1 461²⁹ €

extreme low heat of combustion (LHC)
by a tubular overall jacket
fine stranded bare copper wires

The characteristic feature of this speaker cable is the extremely thin and tubular overall jacket, which has two advantages: beside the costs, also the heat of combustion is kept down - an important criteria in several building installations.

design

conductor: stranded bare copper

core insulation: PVC, red & blue

core arrangement: 2 cores twisted to a pair

outer jacket: PVC, tubular extruded

mechanics

min. bending radius: 5x overall diameter

operating temperature: -20°C / +70°C

flame retardancy: acc. to IEC60332-1

electric

insulation resistance: > 200 MΩ x km

test voltage: 2000 V

max. operating voltage: 300 V

Caracteristici

no. of cores x cross section	2 x 4.0 mm²
cond. construction	56 x 0.30 mm
conductor resistance	4.35 Ω/km
outer Ø	9.2 mm
heat of combustion	225 kWh/km
cable color	black
copper weight	80 g/m
length	300 m
